165012 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
P.G.SPADE
| Part | Insulation | Features | Mounting Type | Contact Material | Width - Outer Edges [y] | Width - Outer Edges [y] | Contact Finish | Material - Insulation | Length - Overall [x] | Length - Overall [x] | Color | Stud/Tab Size | Terminal Type | Length - Termination | Length - Termination | Length - Ring Center to Termination | Length - Ring Center to Termination | Tongue Inside Opening [x] | Tongue Inside Opening [x] | Insulation Diameter [Max] [diameter] | Insulation Diameter [Min] [diameter] | Insulation Diameter [Max] [diameter] | Insulation Diameter [Min] [diameter] | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity Raychem Cable Protection | Insulated | Serrated Termination | Free Hanging (In-Line) | Copper | 0.25 " | 6.35 mm | Tin | Poly-Vinyl Chloride (PVC) | 0.788 in | 20.02 mm | Blue | 8 Stud | Standard | 0.384 in | 9.75 mm | 7.11 mm | 0.28 in | 0.171 in | 4.34 mm | 4.95 mm | 3.05 mm | 0.195 " | 0.12 in | Crimp |
