282808 Series

Catalog

TERM BLOCK PLUG 4POS STR 10MM

Part	Operating Temperature [Min]	Operating Temperature [Max]	Mounting Type	Contact Material	Torque - Screw	Torque - Screw	Number of Positions	Screw Size	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Positions Per Level	Number of Levels	Termination Style	Type	Contact Mating Finish	Insulation Height	Insulation Height	Pitch [x]	Pitch [x]	Color	Material Flammability Rating	Wire Gauge or Range - mm² [Max]	Wire Gauge or Range - mm² [Min]	Wire Strip Length [Max]	Wire Strip Length [Min]	Wire Gauge or Range - mm˛ [Max]	Wire Gauge or Range - mm˛ [Min]
TE Connectivity Raychem Cable Protection 282808-4	-40 °C	110 °C	Free Hanging (In-Line)	Phosphor Bronze	0.79 Nm	7 Lb-In	4	M3	30 AWG	12 AWG	4	1	Screw - Rising Cage Clamp	Plug Female Sockets	Tin	0.61 in	15.49 mm	0.394 in	10 mm	Green	UL94 V-0	2.5 mm²	0.03 mm²	7.5 mm	6 mm
TE Connectivity Raychem Cable Protection 282808-2	-40 °C	110 °C	Free Hanging (In-Line)	Phosphor Bronze	0.79 Nm	7 Lb-In	2	M3	30 AWG	12 AWG	2	1	Screw - Rising Cage Clamp	Plug Female Sockets	Tin	0.61 in	15.49 mm	0.394 in	10 mm	Green	UL94 V-0			7.5 mm	6 mm	2.5 mm˛	0.03 mm²
