ZLG Series

Manufacturer: Rubycon

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - RADIAL LEADED LOW IMPEDANCE ELECTROLYTIC CAPACITORS

Part	Lead Spacing	Lead Spacing	Ripple Current @ Low Frequency	Mounting Type	Impedance	Ripple Current @ High Frequency	Operating Temperature [Min]	Operating Temperature [Max]	Polarization	Package / Case	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension [diameter]	Size / Dimension [diameter]	Tolerance	Applications	Lifetime @ Temp.	Voltage - Rated	Capacitance	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max] [custom]	Height - Seated (Max) [Max]
Rubycon 10ZLG1500MEFC10X23	0.197 "	5 mm	1.416 A	Through Hole	13 mOhms	2.36 A	-40 C	105 ░C	Polar	Can Radial	0.984 in	25 mm	0.394 in	10 mm	20 %	General Purpose	4000 Hrs	10 V	1.5 mF
Rubycon 25ZLG1000MEFC12.5X20	0.197 "	5 mm	1.488 A	Through Hole	13 mOhms	2.48 A	-40 C	105 ░C	Polar	Can Radial			0.492 in	12.5 mm	20 %	General Purpose	5000 Hrs	25 VDC	1000 µF	0.866 in	22 mm
Rubycon 16ZLG120MEFC6.3X11	0.098 in	2.5 mm	372.4 mA	Through Hole	65 mOhms		-40 C	105 ░C	Polar	Can Radial		0.492 in	0.248 "	6.3 mm	20 %	General Purpose	2000 Hrs	16 V	120 µF			12.5 mm
