ALC40 Series

Manufacturer: KEMET

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 63V 5600UF 20% 105C 7000HRS

Part	Lead Spacing	Lead Spacing	Capacitance	ESR (Equivalent Series Resistance)	Size / Dimension	Size / Dimension [diameter]	Ripple Current @ High Frequency	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Lifetime @ Temp.	Ripple Current @ Low Frequency	Tolerance	Polarization	Mounting Type	Voltage - Rated	Applications	Impedance	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case	Size / Dimension [diameter]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Height - Seated (Max)
KEMET ALC40A562CD063	0.394 in	10 mm	5.6 mF	122 mOhm	30 mm	1.181 "	3.03 A	42 mm	1.654 in	7000 Hrs	2.61 A	20 %	Polar	Through Hole	63 V	General Purpose	102 mOhms	-40 C	105 ░C	Radial Can - Snap-In
KEMET ALC40A331CB250	0.394 in	10 mm	330 µF	441 mOhm	30 mm	1.181 "	1.69 A	32 mm	1.26 in	7000 Hrs	1.13 A	20 %	Polar	Through Hole	250 V	General Purpose	312 mOhms	-40 C	105 ░C	Radial Can - Snap-In
KEMET ALC40A102EL400	0.394 in	10 mm	1000 µF	118 mOhm		1.575 in	10.16 A			9000 Hrs	4.85 A	20 %	Polar	Through Hole	400 V	General Purpose	73 mOhms	-40 C	105 ░C	Radial Can - Snap-In	40 mm	3.228 in	82 mm
KEMET ALC40A122DF200	0.394 in	10 mm	1.2 mF	159 mOhm		1.378 "	3.48 A			8000 Hrs	2.5 A	20 %	Polar	Through Hole	200 VDC	General Purpose	119 mOhms	-40 C	105 ░C	Radial Can - Snap-In	35 mm	52 mm		2.047 in
KEMET ALC40C102ED200	0.886 in	22.5 mm	1000 µF	140 mOhm		1.575 in	4.8 A	42 mm	1.654 in	9000 Hrs	3.92 A	20 %	Polar	Through Hole	200 VDC	General Purpose	110 mOhms	-40 C	105 ░C	Radial Can - Snap-In	40 mm
KEMET ALC40A331DC350	0.394 in	10 mm	330 µF	378 mOhm		1.378 "	3.24 A		1.457 in	8000 Hrs	1.79 A	20 %	Polar	Through Hole	350 V	General Purpose	260 mOhms	-40 C	105 ░C	Radial Can - Snap-In	35 mm				37 mm
KEMET ALC40A222DC100	0.394 in	10 mm	2.2 mF	177 mOhm		1.378 "	2.67 A		1.457 in	8000 Hrs	2.1 A	20 %	Polar	Through Hole	100 V	General Purpose	142 mOhms	-40 C	105 ░C	Radial Can - Snap-In	35 mm				37 mm
