HEA2-12 Series

Catalog

DC DC CONVERTER +/-12V 2W

Part	Applications	Features	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Efficiency	Power (Watts)	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Isolation	Voltage - Input (Max) [Max]	Current - Output (Max)	Current - Output (Max)	Package / Case	Mounting Type	Voltage - Output 1	Voltage - Output 2	Type	Voltage - Input (Min) [Min]	Approval Agency	Number of Outputs	Current - Output (Max) [Max]
Daburn Electronics HEA2-12-12	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	85 %	2 W	105 C	-40 °C	1.6 kV	18 V	83 mA	83 mA	8-SIP Module 7 Leads	Through Hole	12 V	-12 V	Isolated Module	9 V	CE	2
Daburn Electronics HEA2-12S15	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	85 %	2 W	105 C	-40 °C	1.6 kV	18 V			8-SIP Module 7 Leads	Through Hole	15 V		Isolated Module	9 V	CE	1	134 mA
Daburn Electronics HEA2-12-15	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	84 %	2 W	105 C	-40 °C	1.6 kV	18 V	67 mA	67 mA	8-SIP Module 7 Leads	Through Hole	15 V	-15 V	Isolated Module	9 V	CE	2
Daburn Electronics HEA2-12S24	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	85 %	2 W	105 C	-40 °C	1.6 kV	18 V			8-SIP Module 7 Leads	Through Hole	24 V		Isolated Module	9 V	CE	1	83 mA
Daburn Electronics HEA2-12S12	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	85 %	2 W	105 C	-40 °C	1.6 kV	18 V			8-SIP Module 7 Leads	Through Hole	12 V		Isolated Module	9 V	CE	1	167 mA
Daburn Electronics HEA2-12-5	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in		2 W	105 C	-40 °C	1.6 kV	18 V			8-SIP Module 7 Leads	Through Hole	5 V	-5 V	Isolated Module	9 V	CE	2
Daburn Electronics HEA2-12S9	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	84 %	2 W	105 C	-40 °C	1.6 kV	18 V			8-SIP Module 7 Leads	Through Hole	9 V		Isolated Module	9 V	CE	1	222 mA
Daburn Electronics HEA2-12S33	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in	78 %	1.7 W	105 C	-40 °C	1.6 kV	18 V			8-SIP Module 7 Leads	Through Hole	3.3 V		Isolated Module	9 V	CE	1	500 mA
Daburn Electronics HEA2-12S5	ITE (Commercial)	Remote On/Off	21.8 mm	0.86 "	9.1 mm	0.44 in	11.2 mm	0.36 in		2 W	105 C	-40 °C	1.6 kV	18 V			8-SIP Module 7 Leads	Through Hole	5 V		Isolated Module	9 V	CE	1	400 mA
