TLHS-V88B Series
Manufacturer: Floyd Bell Inc
Beta
⌘K
BUZZER 35.81MM PNL MNT
| Part | Mounting Type | Input Type | Frequency | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Driver Circuitry | Voltage Range [Max] | Voltage Range [Min] | Port Location | Current - Supply [Min] [x] | Current - Supply [Max] [x] | Approval Agency | Size / Dimension [diameter] | Size / Dimension [diameter] | Ingress Protection | Operating Mode | Termination | Termination | Termination | Sound Pressure Level (SPL) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Floyd Bell Inc | Panel Mount | DC | 2.9 kHz | 1.25 " | 31.75 mm | Indicator Internally Driven | 30 V | 9 V | Top | 50 mA | 110 mA | UL UR | 1.41 in | 35.81 mm | IP68 - Dust Tight Waterproof | Siren | Quick Connect Tab | 0.25 " | 6.35 mm | 103 dB |
 Floyd Bell Inc | Panel Mount | DC | 2.9 kHz | 1.25 " | 31.75 mm | Indicator Internally Driven | 30 V | 9 V | Top | 50 mA | 110 mA | UL UR | 1.41 in | 35.81 mm | IP68 - Dust Tight Waterproof | Siren | Screw Terminal Quick Connect Tab | 0.25 " | 6.35 mm | 103 dB |
