628-5W1 Series
Manufacturer: EDAC Inc.
Catalog
CONN D-SUB RCPT 5POS VERT SLDR
...
| Part | Connector Style | Contact Material | Flange Feature | Contact Type | Number of Rows | Number of Positions | Mounting Type | Shell Size, Connector Layout | Material Flammability Rating | Contact Finish | Termination | Connector Type | Contact Finish Thickness | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Features | Color | Voltage Rating | Current Rating (Amps) | Number of Positions [custom] | Number of Positions [custom] | Shell Material, Finish | Contact Finish Thickness | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Combo D-Sub | Copper Alloy | Board Side (M3) | Signal and Power | 2 | 5 | Through Hole | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Solder | Receptacle Female Sockets | Flash | Polyester Thermoplastic | -55 °C | 125 °C | Shielded | Black | 125 VDC | 5 A 40 A | |||||
 EDAC Inc. | Combo D-Sub | Copper Alloy | 4-40 Board Side | Coax Signal | 2 | Through Hole | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Solder | Receptacle Female Sockets | Flash | Polyester Thermoplastic | -55 °C | 125 °C | Board Lock Shielded | Black | 125 VDC | 4 | 1 | Nickel Plated Steel | ||||
 EDAC Inc. | Combo D-Sub | Copper Alloy | 4-40 | Coax Signal | 2 | Through Hole | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Solder | Receptacle Female Sockets | Flash | Polyester Thermoplastic | -55 °C | 125 °C | Shielded | Black | 125 VDC | 4 | 1 | Nickel Plated Steel | ||||
 EDAC Inc. | Combo D-Sub | Copper Alloy | Board Side (M3) | Signal and Power | 2 | 5 | Through Hole | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Solder | Receptacle Female Sockets | Polyester Thermoplastic | -55 °C | 125 °C | Shielded | Black | 125 VDC | 5 A 40 A | Nickel Plated Steel | 0.76 Ám | 30 Áin | |||
 EDAC Inc. | Combo D-Sub | Copper Alloy | Housing/Shell (Unthreaded) | Coax Signal | 2 | Free Hanging (In-Line) | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Receptacle Female Sockets | Flash | Polyester Thermoplastic | -55 °C | 125 °C | Shielded | Black | 125 VDC | 4 | 1 | ||||||
 EDAC Inc. | Combo D-Sub | Copper Alloy | Board Side (M3) | Coax Signal | 2 | Through Hole | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Solder | Receptacle Female Sockets | Flash | Polyester Thermoplastic | -55 °C | 125 °C | Board Lock Shielded | Black | 125 VDC | 4 | 1 | Nickel Plated Steel | ||||
 EDAC Inc. | Combo D-Sub | Copper Alloy | 4-40 Board Side | Signal and Power | 2 | 5 | Through Hole | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Solder | Receptacle Female Sockets | Polyester Thermoplastic | -55 °C | 125 °C | Shielded | Black | 125 VDC | 5 A 40 A | Nickel Plated Steel | 0.76 Ám | 30 Áin | |||
 EDAC Inc. | Combo D-Sub | Copper Alloy | Board Side (M3) | Coax Signal | 2 | Free Hanging (In-Line) | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Receptacle Female Sockets | Flash | Polyester Thermoplastic | -55 °C | 125 °C | Shielded | Black | 125 VDC | 4 | 1 | ||||||
 EDAC Inc. | Combo D-Sub | Copper Alloy | Housing/Shell (Unthreaded) | Coax Signal | 2 | Free Hanging (In-Line) | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Receptacle Female Sockets | Flash | Polyester Thermoplastic | -55 °C | 125 °C | Shielded | Black | 125 VDC | 4 | 1 | Nickel Plated Steel | |||||
 EDAC Inc. | Combo D-Sub | Copper Alloy | M3 | Signal and Power | 2 | 5 | Through Hole | 1 (DE E) - 5W1 | UL94 V-0 | Gold | Solder | Receptacle Female Sockets | Polyester Thermoplastic | -55 °C | 125 °C | Board Lock Shielded | Black | 125 VDC | 5 A 40 A | 0.76 Ám | 30 Áin |
