EPS060100 Series

Manufacturer: CUI Inc.

Catalog

AC/DC WALL MOUNT ADAPTER 6V 6W

Part	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]	Approval Agency	Polarization	Efficiency	No Load Power Consumption	Output Connector [custom]	Output Connector [custom]	Output Connector	Output Connector [x]	Cord Length	Cord Length	Input Connector	Current - Output (Max) [Max]	Voltage - Output	Applications	Power (Watts)	Voltage - Input [Min]	Voltage - Input [Max]	Form	Region Utilized	Operating Temperature [Max]	Operating Temperature [Min]	Input Type	Output Connector [diameter]
CUI Inc. EPS060100-P5P	1.65 "	26.8 mm	42 mm	1.06 in	62.3 mm	2.45 in	cULus	Positive Center	Level V	300 mW	2.1 mm	5.5 mm	Barrel Plug	12 mm	1.83 m	72 in	NEMA 1-15P	1 A	6 V	ITE (Commercial)	6 W	100 VAC	132 VAC	Wall Mount	North America	40 °C	0 °C	Fixed Blade
CUI Inc. EPS060100-P7P	1.65 "	26.8 mm	42 mm	1.06 in	62.3 mm	2.45 in	cULus	Positive Center	Level V	300 mW			Barrel Plug	9.5 mm	1.83 m	72 in	NEMA 1-15P	1 A	6 V	ITE (Commercial)	6 W	100 VAC	132 VAC	Wall Mount	North America	40 °C	0 °C	Fixed Blade	1.35 mm 3.5 mm
