1393659 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
V42254B1202R480=PC612 MESSERLE
| Part | Material - Insulation | Material Flammability Rating | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions Loaded | Number of Positions | Connector Type | Style | Termination | Mounting Type | Pitch | Pitch | Number of Rows [custom] | Contact Finish | Number of Positions Loaded |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | Glass Filled Polybutylene Terephthalate (PBT) Polyester | UL94 V-0 | -55 C | 125 °C | All | 48 | Plug Male Pins | R/2 (1/2 R) | Solder | Through Hole | 0.1 " | 2.54 mm | 3 | Gold Gold-Palladium | |
 TE Connectivity AMP Connectors | Glass Filled Polybutylene Terephthalate (PBT) Polyester | UL94 V-0 | -55 C | 125 °C | 96 | Plug Male Pins | R | Solder | Through Hole | 0.1 " | 2.54 mm | 3 | Gold Gold-Palladium | 64 | |
 TE Connectivity AMP Connectors | Glass Filled Polybutylene Terephthalate (PBT) Polyester | UL94 V-0 | -55 C | 125 °C | All | 96 | Plug Male Pins | R | Solder | Through Hole | 0.1 " | 2.54 mm | 3 | Gold Gold-Palladium |
