ALC70A Series

Manufacturer: KEMET

Catalog

Catalog

ALUMINUM ELECTROLYTIC CAPACITORS - SNAP IN 450V 360UF 20% 18000HRS

...

Part	Lifetime @ Temp.	Package / Case	Mounting Type	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Ripple Current @ Low Frequency	Impedance	ESR (Equivalent Series Resistance)	Ripple Current @ High Frequency	Applications	Size / Dimension [diameter]	Size / Dimension [diameter]	Tolerance	Polarization	Operating Temperature [Max]	Operating Temperature [Min]	Voltage - Rated	Capacitance	Lead Spacing	Lead Spacing	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Size / Dimension	Height - Seated (Max)	Height - Seated (Max) [Max]
KEMET ALC70A361EB450	18000 Hrs	Radial Can - Snap-In	Through Hole	1.26 in	32 mm	2.1 A	231 mOhms	405 mOhm	4.56 A	General Purpose	1.575 in	40 mm	20 %	Polar	85 °C	-40 C	450 V	360 µF	0.394 in	10 mm
KEMET ALC70A132DF250	15000 Hrs	Radial Can - Snap-In	Through Hole			3.71 A	85 mOhms	145 mOhm	7.33 A	General Purpose	1.378 "	35 mm	20 %	Polar	85 °C	-40 C	250 V	1300 µF	0.394 in	10 mm	2.047 in	52 mm
KEMET ALC70A912BD040	10000 Hrs	Radial Can - Snap-In	Through Hole	1.654 in	42 mm	4.21 A	69 mOhms	83.38 mOhm	5.3 A	General Purpose	0.984 "	25 mm	20 %	Polar	85 °C	-40 C	40 V	9100 µF	0.394 in	10 mm
KEMET ALC70A511EF550	18000 Hrs	Radial Can - Snap-In	Through Hole			2.64 A	749 mOhms	860 mOhm	4.05 A	General Purpose	1.575 in	40 mm	20 %	Polar	85 °C	-40 C	550 V	510 µF	0.394 in	10 mm	2.047 in	52 mm
KEMET ALC70A472CB063	13000 Hrs	Radial Can - Snap-In	Through Hole	1.26 in	32 mm	4.3 A	61 mOhms	81.08 mOhm	6.15 A	General Purpose	1.181 "		20 %	Polar	85 °C	-40 C	63 V	4700 µF	0.394 in	10 mm			30 mm
KEMET ALC70A181DD630	15000 Hrs	Radial Can - Snap-In	Through Hole	1.654 in	42 mm	1.79 A	501 mOhms	727.3 mOhm	3.89 A	General Purpose	1.378 "	35 mm	20 %	Polar	85 °C	-40 C	630 V	180 µF	0.394 in	10 mm
KEMET ALC70A151DC600	15000 Hrs	Radial Can - Snap-In	Through Hole	1.457 in		1.6 A	589 mOhms	852.6 mOhm	3.46 A	General Purpose	1.378 "	35 mm	20 %	Polar	85 °C	-40 C	600 V	150 µF	0.394 in	10 mm				37 mm
KEMET ALC70A752CD063	13000 Hrs	Radial Can - Snap-In	Through Hole	1.654 in	42 mm	5.72 A	39 mOhms	52 mOhm	7.98 A	General Purpose	1.181 "		20 %	Polar	85 °C	-40 C	63 V	7500 µF	0.394 in	10 mm			30 mm
KEMET ALC70A102EL500	18000 Hrs	Radial Can - Snap-In	Through Hole			4.42 A	150 mOhms	209.2 mOhm	8.53 A	General Purpose	1.575 in	40 mm	20 %	Polar	85 °C	-40 C	500 V	1000 µF	0.394 in	10 mm		3.228 in			82 mm
KEMET ALC70A332DC100	15000 Hrs	Radial Can - Snap-In	Through Hole	1.457 in		4.89 A	67 mOhms	83.9 mOhm	6.47 A	General Purpose	1.378 "	35 mm	20 %	Polar	85 °C	-40 C	100 V	3.3 mF	0.394 in	10 mm				37 mm
