LSYMB Series
Manufacturer: Honeywell Sensing and Productivity Solutions
Beta
⌘K
SWITCH SNAP ACTION DPDT 10A 120V
| Part | Differential Travel | Operating Force | Circuit | Overtravel | Mounting Type | Voltage Rating - DC | Features | Switch Function | Termination Style | Operating Temperature [Min] | Operating Temperature [Max] | Actuator Type | Voltage Rating - AC | Pretravel | Current Rating (Amps) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Honeywell Sensing and Productivity Solutions | 10 ° | 46 gfm | DPDT (DB/DM) | 57 ° | Chassis Mount | 115 V | Center Neutral | Mom-Off-Mom | Screw Terminal | -40 °C | 121 °C | Side Rotary - No Lever | 120 V | 18 ° | 10 A 800 mA |
 Honeywell Sensing and Productivity Solutions | 10 ° | 46 gfm | DPDT (DB/DM) | 57 ° | Chassis Mount | 115 V | Center Neutral | Mom-Off-Mom | Screw Terminal | -40 °C | 121 °C | Side Rotary - No Lever | 120 V | 18 ° | 10 A 800 mA |
Honeywell Sensing and Productivity Solutions | 10 ° | 46 gfm | DPDT (DB/DM) | 57 ° | Chassis Mount | 115 V | Front Mounted Steel Roller | Mom-Off-Mom | Plug In | -40 °C | 121 °C | Side Rotary Adjustable Roller | 120 V | 18 ° | 10 A 800 mA |
