GBU6B Series

6 A Bridge Rectifier

Catalog

6 A Bridge Rectifier

Part	Current - Reverse Leakage @ Vr	Technology	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]	Supplier Device Package	Voltage - Forward (Vf) (Max) @ If	Diode Type	Current - Average Rectified (Io)	Package / Case	Voltage - Peak Reverse (Max) [Max]
ON Semiconductor GBU6K	5 µA	Standard	Through Hole	-55 °C	150 °C	GBU	1 V	Single Phase	6 A	4-SIP GBU	800 V
ON Semiconductor GBU6B	5 µA	Standard	Through Hole	-55 °C	150 °C	GBU	1 V	Single Phase	6 A	4-SIP GBU	100 V
ON Semiconductor GBU6A	5 µA	Standard	Through Hole	-55 °C	150 °C	GBU	1 V	Single Phase	6 A	4-SIP GBU	50 V

6 A Bridge Rectifier

• Glass-Passivated Junction

• Surge Overload Rating: 175 A peak

• Reliable Low-Cost Construction Utilizing Molded Plastic Technique

• Ideal for Printed Circuit Bboard

• UL certified, UL #E258596
