PT4583 Series
Manufacturer: Texas Instruments
Beta
⌘K
DC DC CONVERTER 12V 30W
| Part | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [z] | Type | Operating Temperature [Max] | Operating Temperature [Min] | Power (Watts) | Number of Outputs | Voltage - Input (Max) [Max] | Applications | Voltage - Output 1 | Package / Case | Mounting Type | Efficiency | Voltage - Input (Min) [Min] | Voltage - Isolation | Current - Output (Max) [Max] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 1.19 " | 0.5 in | 76.2 mm | 3 " | 30.2 mm | 12.7 mm | Isolated Module | 85 °C | -40 °C | 30 W | 1 | 60 V | ITE (Commercial) | 12 V | 19-SIP Module | Through Hole Right Angle | 86 % | 18 V | 1.5 kV | 2.5 A |
Texas Instruments | 0.67 in | 1.02 in | 76.2 mm | 3 " | 17 mm | 25.9 mm | Isolated Module | 85 °C | -40 °C | 30 W | 1 | 60 V | ITE (Commercial) | 12 V | 19-SIP Module | Through Hole | 86 % | 18 V | 1.5 kV | 2.5 A |
