ATO10PRO Series

Fuse ATO Blade 32V Clamshell 25 pc 10A

Manufacturer: Littelfuse/Commercial Vehicle Products

Catalog

Fuse ATO Blade 32V Clamshell 25 pc 10A

Part	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [x]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [z]	Voltage Rating - DC	Response Time	Fuse Type	Color	Current Rating (Amps)	Voltage Rating - AC	Mounting Type	Package / Case	Approval Agency
Littelfuse/Commercial Vehicle Products 0ATO010.ZXPRO	5.08 mm	12.19 mm	19.05 mm	0.75 in	0.2 "	0.48 in	32 V	Fast Blow	Automotive	Red	10 A	32 V	Requires Holder	ATC ATO Blade	CSA SAE UL

Catalog

Fuse ATO Blade 32V Clamshell 25 pc 10A

Key Features

• Red housing indicates 10 A rating

• Net weight 1.4 g

• Complies with SAE J1284 and ISO 8820-3

• UL Listed (File AU 1410)

• CSA Certified (File No. 29862)

Description

This 10 A ATO® 287 Series automotive blade fuse protects low-voltage circuits in most automobiles sold around the world. Rated at 32 V, the fast-acting fuse performs similarly to ATOF®, ATO Smart Glow, and ATO Silver fuses.
