Encapsulated Power Supply 24V 25 Watt
Encapsulated Power Supply 24V 25 Watt
| Part | Power (Watts) | Features | Mounting Type | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Voltage - Output 1 | Applications | Current - Output (Max) [Max] | Number of Outputs | Approval Agency | Voltage - Input [Min] | Voltage - Input [Max] | Package / Case | Efficiency | Type | Standard Number | Voltage - Isolation | Current - Output 1 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TT Electronics/BI | 25 W | Universal Input | Through Hole | 23.5 mm | 0.93 " | 1.08 in | 27.5 mm | 52.5 mm | 2.07 in | 24 V | Household Appliances ITE (Commercial) | 1.042 A | 1 | CB CE cURus | 90 VAC 127 VDC | 305 VAC 430 VDC | 4-DIP Module | 87 % | Enclosed | 60335-1 60950-1 62368-1 | ||
 TT Electronics/BI | 25 W | DC Input Capable Universal Input | Chassis Mount | 96 mm | 3.78 in | 1.14 " | 29 mm | 53.8 mm | 2.12 in | 15 V | Household Appliances ITE (Commercial) | 1 | CB CE cURus | 90 VAC 127 VDC | 305 VAC 430 VDC | 88 % | Enclosed | 60335-1 60950-1 62368-1 | 4000 V | 1.666 A | ||
 TT Electronics/BI | 25 W | DC Input Capable Universal Input | Chassis Mount | 96 mm | 3.78 in | 1.14 " | 29 mm | 53.8 mm | 2.12 in | 24 V | Household Appliances ITE (Commercial) | 1 | CB CE cURus | 90 VAC 127 VDC | 305 VAC 430 VDC | 87 % | Enclosed | 60335-1 60950-1 62368-1 | 4000 V | 1.042 A | ||
 TT Electronics/BI | 25 W | Universal Input | Through Hole | 23.5 mm | 0.93 " | 1.08 in | 27.5 mm | 52.5 mm | 2.07 in | 15 V | Household Appliances ITE (Commercial) | 1.666 A | 1 | CB CE cURus | 90 VAC 127 VDC | 305 VAC 430 VDC | 4-DIP Module | 88 % | Enclosed | |||
TT Electronics/BI | 25 W | DC Input Capable Universal Input | Chassis Mount | 96 mm | 3.78 in | 1.14 " | 29 mm | 53.8 mm | 2.12 in | 12 V | Household Appliances ITE (Commercial) | 1 | CB CE cURus | 90 VAC 127 VDC | 305 VAC 430 VDC | 88 % | Enclosed | 60335-1 60950-1 62368-1 | 4000 V | 2.083 A | ||
TT Electronics/BI | 20 W | Universal Input | Through Hole | 23.5 mm | 0.93 " | 1.08 in | 27.5 mm | 52.5 mm | 2.07 in | 5.1 V | Household Appliances ITE (Commercial) | 3.922 A | 1 | CB CE cURus | 90 VAC 127 VDC | 305 VAC 430 VDC | 4-DIP Module | 84 % | Enclosed | 60335-1 60950-1 62368-1 | ||
 TT Electronics/BI | 20 W | DC Input Capable Universal Input | Chassis Mount | 96 mm | 3.78 in | 1.14 " | 29 mm | 53.8 mm | 2.12 in | 5.1 V | Household Appliances ITE (Commercial) | 1 | CB CE cURus | 90 VAC 127 VDC | 305 VAC 430 VDC | 84 % | Enclosed | 60335-1 60950-1 62368-1 | 4000 V | 3.922 A |
