857-032 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 32POS 0.156
| Part | Termination Rows | Material - Insulation | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Card Type | Pitch | Pitch | Gender | Contact Type | Termination | Number of Rows | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Read Out | Number of Positions/Bay/Row | Contact Finish | Mounting Type | Color | Termination Rows [custom] | Number of Rows [custom] | Features | Number of Positions |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder | 1 | 125 °C | -40 C | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Single | 32 | Gold | Right Angle Through Hole | Black | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Wire Wrap | 1 | 125 °C | -40 C | Copper Alloy | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Single | 32 | Tin | Through Hole | Black | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder | 125 °C | -40 C | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 16 | Tin | Board Edge Straddle Mount | Black | 2 | 2 | Card Extender | |||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder | 1 | 125 °C | -40 C | Copper Alloy | Flush Mount M3 Threaded Insert Top Opening | Single | 32 | Gold | Right Angle Through Hole | Black | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder | 125 °C | -40 C | Copper Alloy | Dual | 16 | Gold | Board Edge Straddle Mount | Black | 2 | 2 | Card Extender | ||||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder | 125 °C | -40 C | Copper Alloy | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Single | 16 | Gold | Right Angle Through Hole | Black | 2 | 2 | ||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Single Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Wire Wrap | 1 | 125 °C | -40 C | Copper Alloy | Single | 32 | Tin | Through Hole | Black | |||||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder | 125 °C | -40 C | Copper Alloy | Dual | 32 | Gold | Right Angle Through Hole | Black | 2 | 64 | ||||||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder | 125 °C | -40 C | Copper Alloy | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Dual | 32 | Gold | Through Hole | Black | 2 | 64 | |||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Non Specified - Dual Edge | 3.96 mm | 0.156 in | Female | Semi Bellows | Solder Eyelet(s) | 125 °C | -40 C | Copper Alloy | 4-40 Flush Mount Threaded Insert Top Opening | Dual | 32 | Gold | Through Hole | Black | 2 | 64 |
