123-8 Series
Manufacturer: 3M Electronic Specialty
Beta
⌘K
CONN RING CIRC 12-16AWG #8 CRIMP
| Part | Insulation Diameter [diameter] | Insulation Diameter [diameter] | Material - Insulation | Wire Gauge [Max] | Wire Gauge [Min] | Insulation | Length - Overall [x] | Length - Overall [x] | Terminal Type | Stud/Tab Size | Contact Finish | Termination | Contact Material | Mounting Type | Thickness | Thickness | Features | Width - Outer Edges [x] | Width - Outer Edges [x] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 3M Electronic Specialty | 6.35 mm | 0.25 in | Nylon Polyamide (PA) | 16 AWG | 12 AWG | Insulated | 0.98 in | 24.89 mm | Circular | 8 Stud | Tin | Crimp | Copper ETP | Free Hanging (In-Line) | 50 mils | 0.05 in | Butted Seam Heavy Duty | 7.11 mm | 0.28 in |
