RZE25 Series
Manufacturer: Sullins Connector Solutions
Beta
⌘K
CONN EDGE DUAL FMALE 50POS 0.039
| Part | Material - Insulation | Card Thickness | Card Thickness | Gender | Mounting Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions/Bay/Row | Termination | Number of Rows [custom] | Contact Type | Contact Material | Contact Finish Thickness | Contact Finish Thickness | Color | Pitch | Pitch | Number of Positions | Read Out | Contact Finish | Card Type | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | 1.57 mm | 0.062 in | Female | Through Hole | -65 ░C | 125 °C | 25 | Solder Staggered | 2 | Hairpin Bellows | Phosphor Bronze | 0.25 Ám | 10 Áin | Black | 1 mm | 0.039 in | 50 | Dual | Gold | Non Specified - Dual Edge | |
 Sullins Connector Solutions | Polyphenylene Sulfide (PPS) | 1.57 mm | 0.062 in | Female | Surface Mount | -65 ░C | 125 °C | 25 | Solder | 2 | Hairpin Bellows | Phosphor Bronze | 0.25 Ám | 10 Áin | Black | 1 mm | 0.039 in | 50 | Dual | Gold | Non Specified - Dual Edge | Board Lock |
