1313A Series
Manufacturer: Belden Inc.
Beta
⌘K
2 #10 PE FRPVC
| Part | Usage | Jacket Color | Number of Conductors | Conductor Strand [custom] | Conductor Strand [custom] | Jacket (Insulation) Material | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Features | Voltage | Length | Length | Conductor Material | Wire Gauge | Conductor Insulation | Cable Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Belden Inc. | Audio-Video Home | Black | 2 | 34 AWG | 259 | Poly-Vinyl Chloride (PVC) | 0.044 in | 1.118 mm | 0.428 " | 10.87 mm | Direct Burial | 300 VDC | 304.8 m | 1000 ft | Copper Bare | 10 AWG | Polyethylene (PE) | Speaker |
Belden Inc. | Audio-Video Home | Black | 2 | 34 AWG | 259 | Poly-Vinyl Chloride (PVC) | 0.044 in | 1.118 mm | 0.428 " | 10.87 mm | Direct Burial | 300 VDC | 152.4 m | 500 ft | Copper Bare | 10 AWG | Polyethylene (PE) | Speaker |
 Belden Inc. | Audio-Video Home | Gray | 2 | 34 AWG | 259 | Poly-Vinyl Chloride (PVC) | 0.044 in | 1.118 mm | 0.428 " | 10.87 mm | Direct Burial | 300 VDC | 304.8 m | 1000 ft | Copper Bare | 10 AWG | Polyethylene (PE) | Speaker |
Belden Inc. | Audio-Video Home | White | 2 | 34 AWG | 259 | Poly-Vinyl Chloride (PVC) | 0.044 in | 1.118 mm | 0.428 " | 10.87 mm | Direct Burial | 300 VDC | 152.4 m | 500 ft | Copper Bare | 10 AWG | Polyethylene (PE) | Speaker |
