CGS RLW73 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
RES, R1, 1%, 0.75W, 0612 W, THICK FILM ROHS COMPLIANT: YES
| Part | Number of Terminations [custom] | Tolerance | Features | Composition | Height - Seated (Max) [Max] [z] | Height - Seated (Max) [Max] [z] | Package / Case | Operating Temperature [Max] | Operating Temperature [Min] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Power (Watts) | Power (Watts) | Temperature Coefficient | Supplier Device Package | Resistance | Supplier Device Package |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 0612 Wide 1206 (3216 Metric) | 155 C | -55 C | 3.2 mm | 0.063 " | 1.6 mm | 0.126 in | 3/4W | 0.75 W | 200 ppm/°C | 0612 | 0.1 Ohms | |
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 0612 Wide 1206 (3216 Metric) | 155 C | -55 C | 3.2 mm | 0.063 " | 1.6 mm | 0.126 in | 1.5 W | 200 ppm/°C | 0612 | 0.15 Ohms | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 1225 Wide 2512 (6432 Metric) | 155 C | -55 C | 6.3 mm | 0.122 " | 3.1 mm | 0.248 in | 3 W | 200 ppm/°C | 0.1 Ohms | 1225 | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 1020 Wide 2010 (5025 Metric) | 155 C | -55 C | 5 mm | 0.098 in | 2.5 mm | 0.197 " | 2 W | 600 ppm/°C | 1020 | 15 mOhms | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 1020 Wide 2010 (5025 Metric) | 155 C | -55 C | 5 mm | 0.098 in | 2.5 mm | 0.197 " | 2 W | 200 ppm/°C | 1020 | 470 mOhms | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 1225 Wide 2512 (6432 Metric) | 155 C | -55 C | 6.3 mm | 0.122 " | 3.1 mm | 0.248 in | 1.5 W | 200 ppm/°C | 0.12 Ohms | 1225 | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 1020 Wide 2010 (5025 Metric) | 155 C | -55 C | 5 mm | 0.098 in | 2.5 mm | 0.197 " | 1 W | 200 ppm/°C | 1020 | 0.068 Ohms | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 0508 Wide 0805 (2012 Metric) | 155 C | -55 C | 2 mm | 0.049 in | 1.25 mm | 0.079 in | 1 W | 200 ppm/°C | 0508 | 390 mOhms | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 1225 Wide 2512 (6432 Metric) | 155 C | -55 C | 6.3 mm | 0.122 " | 3.1 mm | 0.248 in | 3 W | 200 ppm/°C | 0.1 Ohms | 1225 | ||
 TE Connectivity AMP Connectors | 2 | 1 % | Current Sense | Thick Film | 0.7 mm | 0.028 " | 0508 Wide 0805 (2012 Metric) | 155 C | -55 C | 2 mm | 0.049 in | 1.25 mm | 0.079 in | 1 W | 200 ppm/°C | 0508 | 0.18 Ohms |
