AHU1 Series
Manufacturer: CIT Relay and Switch
Beta
⌘K
SWITCH PB SPDT 3A 125V
| Part | Electrical Life | Mechanical Life | Termination Style | Illumination Type, Color | Panel Cutout Dimensions [diameter] | Circuit | Voltage Rating - AC | Features | Type | Mounting Type | Actuator Type | Current Rating (Amps) | Ingress Protection | Actuator Marking | Color - Actuator/Cap | Switch Function | Illumination Voltage (Nominal) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 CIT Relay and Switch | 50000 Cycles | 500000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Green LED | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-On | |
 CIT Relay and Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Green LED | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-Mom | 24 V |
 CIT Relay and Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Green LED | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-Mom | 12 VDC |
 CIT Relay and Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Blue LED | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-Mom | |
 CIT Relay and Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Green LED | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-Mom | |
 CIT Relay and Switch | 50000 Cycles | 500000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Green LED | 19 mm | SPDT | 125 V | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Black | On-On | ||
 CIT Relay and Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | LED Red | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-Mom | |
 CIT Relay and Switch | 50000 Cycles | 500000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | LED Red | 19 mm | SPDT | 125 V | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Black | On-On | ||
 CIT Relay and Switch | 50000 Cycles | 1000000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | Blue LED | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-Mom | |
 CIT Relay and Switch | 50000 Cycles | 500000 Cycles | Solder Quick Connect - 0.110" (2.8mm) | LED Red | 19 mm | SPDT | 125 V | Stainless Steel | Anti-Vandal Illuminated | Panel Mount Front | Button Flush Round | 3 A | IP67 - Dust Tight Waterproof | No Marking | Silver | On-On |
