QUINT-PS Series

Catalog

DIN RAIL POWER SUPPLIES ASSY ADAPTER

Part	Accessory Type	Efficiency	Voltage - Isolation	AC Voltage - Input [Max]	AC Voltage - Input [Min]	DC Voltage - Input (Max) [Max]	Power (Watts)	Current - Output (Max) [Max]	Applications	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Operating Temperature [Max]	Operating Temperature [Min]	DC Voltage - Input (Min) [Min]	Voltage - Output 1	Input Type	Features	Approval Agency	Number of Outputs	Size / Dimension [y]	Size / Dimension [z]
Phoenix Contact 2938196	Adapter - Mounting
Phoenix Contact 2320827		93 %	4000 V	575 VAC 575 VAC	320 VAC 360 VAC	800 V	960 W	20 A	ITE (Commercial)	6.93 "	130 mm	5.12 in	96 mm	3.78 in	176 mm	70 °C	-25 °C	450 V	48 V	AC or DC	Adjustable Output IP20 Load Sharing Universal Input	CB cULus cURus	1
Phoenix Contact 2866792		93 %	4000 V	575 VAC 575 VAC	320 VAC 360 VAC	800 V	480 W	20 A	ITE (Commercial)	4.92 in		5.12 in		2.72 "	125 mm	70 °C	-25 °C	450 V	24 V	AC or DC	Adjustable Output IP20 Load Sharing Universal Input	CB cULus cURus	1	69 mm	130 mm
