Medical Desktop Power Supply 15V 135 Watt
Medical Desktop Power Supply 15V 135 Watt
| Part | Voltage - Input [Max] | Voltage - Input [Min] | Input Type | Cord Length | Cord Length | Current - Output (Max) [Max] | Input Connector | Voltage - Output | Applications | Region Utilized | Efficiency | Form | Standard Number | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Output Connector | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Power (Watts) | No Load Power Consumption |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TT Electronics/BI | 264 VAC | 90 VAC | Cord (Sold Separately) | 47 in | 1.2 m | 11 A | IEC 320-C18 | 12 V | Medical | International | Level IV | Desktop (Class II) | 60601-1 | 0 °C | 60 °C | CE cURus TUV | Power DIN 4 Pin | 207.5 mm | 24.4 mm | 3.23 in | 8.17 in | 0.96 in | 82 mm | 132 W | |
 TT Electronics/BI | 264 VAC | 90 VAC | Cord (Sold Separately) | 47 in | 1.2 m | 12.5 A | IEC 320-C14 | 12 V | Medical | International | Level VI | Desktop (Class I) | 60601-1 | 0 °C | 60 °C | CB CCC CE cURus PSE UKCA | 170 mm | 42.5 mm | 3.35 in | 6.69 in | 1.67 in | 85 mm | 150 W | 210 mW | |
TT Electronics/BI | 264 VAC | 90 VAC | Cord (Sold Separately) | 47 in | 1.2 m | 6.25 A | IEC 320-C18 | 24 V | Medical | International | Level V | Desktop (Class II) | 60601-1 | 0 °C | 60 °C | CE cURus TUV | Power DIN 4 Pin | 207.5 mm | 24.4 mm | 3.23 in | 8.17 in | 0.96 in | 82 mm | 150 W | |
 TT Electronics/BI | 264 VAC | 90 VAC | Cord (Sold Separately) | 47 in | 1.2 m | 6.25 A | IEC 320-C14 | 24 V | Medical | International | Level VI | Desktop (Class I) | 60601-1 | 0 °C | 60 °C | CB CCC CE cURus PSE UKCA | 170 mm | 42.5 mm | 3.35 in | 6.69 in | 1.67 in | 85 mm | 150 W | 210 mW | |
TT Electronics/BI | 264 VAC | 90 VAC | Cord (Sold Separately) | 47 in | 1.2 m | 9 A | IEC 320-C18 | 15 V | Medical | International | Level IV | Desktop (Class II) | 60601-1 | 0 °C | 60 °C | CE cURus TUV | Power DIN 4 Pin | 207.5 mm | 24.4 mm | 3.23 in | 8.17 in | 0.96 in | 82 mm | 135 W | |
TT Electronics/BI | 264 VAC | 90 VAC | Cord (Sold Separately) | 47 in | 1.2 m | 10 A | IEC 320-C14 | 15 V | Medical | International | Level VI | Desktop (Class I) | 60601-1 | 0 °C | 60 °C | CB CCC CE cURus PSE UKCA | 170 mm | 42.5 mm | 3.35 in | 6.69 in | 1.67 in | 85 mm | 150 W | 210 mW |
