D0814 Series
Manufacturer: Harwin Inc.
Beta
⌘K
CONN IC DIP SOCKET 14POS GOLD
| Part | Material Flammability Rating | Termination Post Length | Termination Post Length | Contact Resistance | Current Rating (Amps) | Contact Material - Post [custom] | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Contact Material - Mating | Contact Finish - Mating | Mounting Type | Termination | Features | Operating Temperature [Min] | Operating Temperature [Max] | Type | Type | Type | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Contact Finish - Post | Pitch - Post | Pitch - Post | Pitch - Mating | Pitch - Mating | Housing Material | Number of Positions or Pins (Grid) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Harwin Inc. | UL94 V-0 | 12.95 mm | 0.51 " | 10 mOhm | 1 A | Brass | 0.25 µm | 10 µin | Beryllium Copper | Gold | Through Hole | Wire Wrap | Open Frame | -55 C | 125 °C | 7.62 mm | 0.3 in | DIP | 5 µm | 196.9 µin | Tin | 0.1 in | 2.54 mm | 0.1 " | 2.54 mm | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | 14 |
