16_N-50 Series
Manufacturer: Huber+Suhner, Inc.
Beta
⌘K
16_N-50-2-6/133_NE
| Part | Body Finish | Mating Cycles | Voltage Rating | Body Material | Center Contact Plating | Dielectric Material | Operating Temperature [Min] | Operating Temperature [Max] | Frequency - Max [Max] | Connector Style | Cable Group | Housing Color | Center Contact Material | Fastening Type | Mounting Type | Shield Termination | Number of Ports | Impedance | Contact Termination | Connector Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Huber+Suhner, Inc. | White Bronze | 500 | 1000 VDC | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | 11 GHz | N Type | RD-316 | Silver | Brass | Threaded | Free Hanging (In-Line) Right Angle | Crimp | 1 | 50 Ohms | Solder | Plug Male Pin |
 Huber+Suhner, Inc. | White Bronze | 500 | 1000 VDC | Brass | Gold | -65 ░C | 165 °C | 11 GHz | N Type | Silver | Brass | Threaded | Free Hanging (In-Line) Right Angle | Crimp | 1 | 50 Ohms | Solder | Plug Male Pin | ||
 Huber+Suhner, Inc. | 11 GHz | N Type | Silver | Brass | Threaded | Free Hanging (In-Line) Right Angle | Crimp | 1 | 50 Ohms | Solder | Plug Male Pin | |||||||||
 Huber+Suhner, Inc. | White Bronze | 500 | 1000 VDC | Brass | Gold | Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | 11 GHz | N Type | LMR-195 | Silver | Brass | Threaded | Free Hanging (In-Line) Right Angle | Crimp | 1 | 50 Ohms | Solder | Plug Male Pin |
 Huber+Suhner, Inc. | Nickel | 500 | 1000 VDC | Brass | Gold | Polytetrafluoroethylene (PTFE) | -60 °C | 165 °C | 15 GHz | N Type | RG-B4C | Silver | Beryllium Copper | Threaded | Free Hanging (In-Line) Right Angle | Clamp | 1 | 50 Ohms | Crimp | Plug Male Pin |
 Huber+Suhner, Inc. | White Bronze | 500 | 1000 VDC | Brass | Silver | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | -40 C | 85 °C | 11 GHz | N Type | Silver | Brass | Threaded | Free Hanging (In-Line) Right Angle | Clamp | 1 | 50 Ohms | Crimp | Plug Male Pin | |
 Huber+Suhner, Inc. | Silver | 500 | 1000 VDC | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | 11 GHz | N Type | Silver | Brass | Threaded | Free Hanging (In-Line) Right Angle | Crimp | 1 | 50 Ohms | Solder | Plug Male Pin | |
 Huber+Suhner, Inc. | White Bronze | 500 | 1000 VDC | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | 11 GHz | N Type | Silver | Brass | Threaded | Free Hanging (In-Line) Right Angle | Crimp | 1 | 50 Ohms | Solder | Plug Male Pin | |
 Huber+Suhner, Inc. | White Bronze | 500 | 1000 VDC | Brass | Gold | Perfluoroalkoxy (PFA) Polytetrafluoroethylene (PTFE) | -65 ░C | 165 °C | 11 GHz | N Type | 393 RG-225 | Silver | Brass Bronze | Threaded | Free Hanging (In-Line) Right Angle | Crimp | 1 | 50 Ohms | Crimp | Plug Male Pin |
 Huber+Suhner, Inc. | White Bronze | 500 | 1000 VDC | Brass | Silver | -40 C | 85 °C | 11 GHz | N Type | 1/2" Helical | Silver | Brass Bronze | Threaded | Free Hanging (In-Line) Right Angle | Clamp | 1 | 50 Ohms | Crimp | Plug Male Pin |
