801-87 Series
Manufacturer: Preci-Dip
Beta
⌘K
CONN SOCKET 7POS 0.1 GOLD SMD
| Part | Contact Material | Contact Shape | Insulation Material | Contact Finish - Post | Connector Type | Material Flammability Rating | Features | Fastening Type | Operating Temperature [Min] | Operating Temperature [Max] | Pitch - Mating | Pitch - Mating | Contact Finish Thickness - Mating | Number of Positions Loaded | Number of Positions | Number of Rows | Current Rating (Amps) | Contact Type | Insulation Height | Insulation Height | Contact Finish - Mating | Insulation Color | Termination | Mounting Type | Contact Length - Post | Contact Length - Post | Contact Length - Post [x] | Contact Length - Post [x] | Contact Length - Post [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Pick and Place | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 7 | 1 | 3 A | Female Socket | 5.6 mm | 0.22 in | Gold | Black | Solder | Surface Mount | |||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 18 | 1 | 3 A | Female Socket | 7 mm | 0.276 in | Gold | Black | Kinked Pin Solder | Through Hole | 0.118 in | 3 mm | ||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Pick and Place | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 7 | 1 | 3 A | Female Socket | 2.54 mm | 0.1 in | Gold | Black | Solder | Right Angle Surface Mount | |||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 23 | 1 | 3 A | Female Socket | 2.54 mm | 0.1 in | Gold | Black | Solder | Right Angle Through Hole | 0.126 " | 3.2 mm | ||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 37 | 1 | 3 A | Female Socket | 7 mm | 0.276 in | Gold | Black | Press-Fit Solder | Through Hole | 2.79 mm | 0.11 in | ||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 7 | 1 | 3 A | Female Socket | 7 mm | 0.276 in | Gold | Black | Kinked Pin Solder | Through Hole | 0.118 in | 3 mm | ||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 15 | 1 | 3 A | Female Socket | 7 mm | 0.276 in | Gold | Black | Kinked Pin Solder | Through Hole | 0.118 in | 3 mm | ||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 1 | 3 A | Female Socket | 5.6 mm | 0.22 in | Gold | Black | Solder | Surface Mount | |||||||
Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 23 | 1 | 3 A | Female Socket | 7 mm | 0.276 in | Gold | Black | Kinked Pin Solder | Through Hole | 0.118 in | 3 mm | ||||
 Preci-Dip | Beryllium Copper | Circular | Glass Filled Polycyclohexylenedimethylene Terephthalate (PCT) Polyester | Tin | Socket | UL94 V-0 | Push-Pull | -55 C | 125 °C | 0.1 " | 2.54 mm | Flash | All | 19 | 1 | 3 A | Female Socket | 37.5 mm | 1.476 in | Gold | Black | Solder | Through Hole | 0.118 in | 3 mm |
