9BFB12 Series
Manufacturer: Sanyo Denki America Inc.
Beta
⌘K
DC BLOWER CENTRIFUGAL BALL BEARING 12V 10.8V TO 13.2V 56.5CFM 62DB 120 X 120 X 32MM
| Part | Material - Blade | Material - Frame | Voltage Range [Min] | Voltage Range [Max] | Current Rating (Amps) | Lifetime @ Temp. | Termination | Power (Watts) | Noise | Bearing Type | Operating Temperature [Min] | Operating Temperature [Max] | Approval Agency | Width [y] | RPM | Weight [custom] | Weight [custom] | Air Flow | Air Flow | Features | Voltage - Rated | Size / Dimension | Size / Dimension [y] | Size / Dimension [x] | Fan Type | Static Pressure | Static Pressure |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Sanyo Denki America Inc. | Plastic | Plastic | 10.8 VDC | 13.2 VDC | 2.3 A | 40000 Hrs | 4 Wire Leads | 27.6 W | 62 dB(A) | Ball | -20 ░C | 70 °C | cURus TUV | 32 mm | 3750 RPM | 340.19 g | 0.75 lb | 56.5 CFM | 1.58 m³/min | Locked Rotor Protection PWM Control Speed Sensor (Tach) | 12 VDC | Square/Rounded | 120 mm | 120 mm | Blower | 1250 Pa | 5.02 in H2O |
