637-M15 Series
Manufacturer: EDAC Inc.
Beta
⌘K
MACHINED D-SUB CONNECTORS ROHS COMPLIANT: YES
| Part | Dielectric Material | Contact Material | Color | Operating Temperature [Min] | Operating Temperature [Max] | Connector Style | Contact Type | Mounting Type | Features | Contact Finish | Contact Finish Thickness | Contact Finish Thickness | Shell Size, Connector Layout [custom] | Shell Size, Connector Layout [custom] | Number of Rows [custom] | Material Flammability Rating | Current Rating (Amps) | Flange Feature | Number of Positions | Connector Type | Shell Material, Finish | Flange Feature | Termination | Contact Finish Thickness |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Free Hanging (In-Line) | Grounding Indents Shielded | Gold | 0.38 µm | 15 µin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell (Unthreaded) | 15 | Plug Male Pins | ||||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Through Hole | Grounding Indents Shielded | Gold | 0.76 Ám | 30 Áin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | Nickel Plated Steel | 4-40 | Solder | |
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Free Hanging (In-Line) | Grounding Indents Shielded | Gold | 0.76 Ám | 30 Áin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | 4-40 | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Free Hanging (In-Line) | Grounding Indents Shielded | Gold | 0.38 µm | 15 µin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | Nickel Plated Steel | 4-40 | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Through Hole | Grounding Indents Shielded | Gold | 0.38 µm | 15 µin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | Nickel Plated Steel | 4-40 | Solder | |
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Through Hole | Grounding Indents Shielded | Gold | 0.38 µm | 15 µin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | 4-40 | Solder | ||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Free Hanging (In-Line) | Board Lock Grounding Indents Shielded | Gold | 0.38 µm | 15 µin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | 4-40 | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Free Hanging (In-Line) | Grounding Indents Shielded | Gold | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | Nickel Plated Steel | 4-40 | Flash | |||
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Through Hole | Board Lock Grounding Indents Shielded | Gold | 0.38 µm | 15 µin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | Nickel Plated Steel | 4-40 | Solder | |
 EDAC Inc. | Nylon 9T Polyamide (PA9T) | Copper Alloy | Black | -55 C | 125 °C | D-Sub High Density | Signal | Free Hanging (In-Line) | Grounding Indents Shielded | Gold | 0.38 µm | 15 µin | (DE E) High Density | 1 | 3 | UL94 V-0 | 5 A | Housing/Shell | 15 | Plug Male Pins | Nickel Plated Steel | 4-40 |
