MS3110E20 Series

Catalog

MS3110E20-24P

Part	Shell Size - Insert (Minimum)	Shell Size - Insert (Maximum)	Mounting Feature	Ingress Protection	Material Flammability Rating	Connector Type	Termination	Contact Finish - Mating	Number of Positions	Color	Voltage Rating	Operating Temperature (Min)	Operating Temperature (Max)	Orientation	Applications	Fastening Type	Mounting Type	Shielding	Grade	Contact Material	Primary Material	Shell Size - Insert Length	Shell Size - Insert Width	Qualification	Shell Material	Backshell Material	Plating	Features	Shell Finish	Insert Material
Amphenol Aerospace Operations MS3110E20-24P	20	24	Flange	Weathertight	UL94 V-0	Male Pins Receptacle	Solder Cup	Gold	24 pos	Olive Drab	500 V	-65 °C	150 °C	N (Normal)	Aerospace Aviation Military	Bayonet Lock	Panel Mount
Amphenol Aerospace Operations MS3110E20-16P			Flange	Environment Resistant		Male Pins Receptacle	Solder Cup	Gold	16	Olive Drab		-55 °C	125 °C	N (Normal)	Aerospace Communication Systems Industrial Instrumentation Mass Transit Military	Bayonet Lock	Panel Mount	Unshielded	Military	Copper Alloy	Metal	20 mm	16 mm	MIL-DTL-26482 Series I	Aluminum	Aluminum	Olive Drab Chromate over Cadmium	Backshell	Cadmium Olive Drab Chromate	Neoprene
Amphenol Aerospace Operations MS3110E20-41P
Amphenol Aerospace Operations MS3110E20-41S
Amphenol Aerospace Operations MS3110E20-39P
