CFB700 Series
Manufacturer: Cincon Electronics Co. LTD
Beta
⌘K
MODULE DC-DC 48VIN 1-OUT 28V 25A 700W 16-PIN BRICK BOX
| Part | Standard Number | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Voltage - Input (Max) [Max] | Efficiency | Control Features | Voltage - Output 1 | Number of Outputs | Operating Temperature [Min] | Operating Temperature [Max] | Current - Output (Max) [Max] | Package / Case | Supplier Device Package | Applications | Mounting Type | Approval Agency | Type | Power (Watts) | Voltage - Input (Min) [Min] | Voltage - Isolation | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Cincon Electronics Co. LTD | 60950-1 | 2.4 in | 4.6 " | 12.7 mm | 0.5 in | 61 mm | 116.8 mm | 75 V | 91 % | Active Low Enable | 28 V | 1 | -40 C | 100 °C | 25 A | Full Brick | Full Brick | ITE (Commercial) | Through Hole | CE cURus | Isolated Module | 700 W | 36 V | 1.5 kV | Remote On/Off |
