Atmos Series
Manufacturer: Taoglas Limited
Coming soon—Zenode’s new Cross Ref’s tool! RSVP for the webinar here to get early access
Beta
⌘K
MODULAR CONNECTORS / ETHERNET CONNECTORS CONN JACK 2PORT 1000 BASE-T
| Part | Operating Temperature (Min) | Operating Temperature (Max) | Orientation Angle | Orientation Direction | Tab Direction | LED Color | Applications | Shielding | Height Above Board | Number of Cores per Jack | Contact Material | Contact Finish | Number of Ports | Number of Rows | Connector Type | Termination | Features | Mounting Type | Shield Material | Housing Material | Contact Finish Thickness | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Taoglas Limited | -40 °C | 85 °C | 90 ° | Right | Down Up | Green Yellow - Green | 1G Base-T AutoMDIX | EMI Finger Shielded | 1.05 in | 8 | Copper Alloy | Gold | 2 | 2 | RJ45 | Solder | Board Guide | Through Hole | Copper Alloy | Thermoplastic | 6 µin | |
 Taoglas Limited | 0 °C | 70 °C | 90 ° | Right | Up | Green - Green | 1G Base-T | EMI Finger Shielded | 0.531 in | 12 | Phosphor Bronze | Gold | 1 | 1 | RJ45 | Solder | Board Guide | Through Hole | ||||
 Taoglas Limited | -40 °C | 85 °C | Up | Green Orange - Yellow | 1G Base-T AutoMDIX Power over Ethernet (PoE) | EMI Finger Shielded | 0.531 in | 8 | Phosphor Bronze | Gold | 4 | 1 | RJ45 | Solder | Board Guide | Through Hole | Brass | Thermoplastic | 50 µin | Vertical | ||
 Taoglas Limited | 0 °C | 70 °C | 90 ° | Right | Up | Green - Yellow | 10/100 Base-T AutoMDIX | EMI Finger Shielded | 0.53 in | 4 | Phosphor Bronze | Gold | 1 | 1 | RJ45 | Solder | Board Lock | Through Hole | Stainless Steel | Glass Filled PBT Polybutylene Terephthalate | 6 µin | |
 Taoglas Limited | -40 °C | 85 °C | 90 ° | Right | Down | Green - Yellow | 10/100 Base-T AutoMDIX | EMI Finger Shielded | 0.53 in | 4 | Phosphor Bronze | Gold | 1 | 1 | RJ45 | Solder | Board Guide | Through Hole | Brass | PBT Polybutylene Terephthalate | 15 µin | |
 Taoglas Limited | -40 °C | 85 °C | 90 ° | Right | Down | Green - Yellow | 10/100 Base-T AutoMDIX | Unshielded | 0.524 in | 4 | Phosphor Bronze | Gold | 1 | 1 | RJ45 | Solder | Board Guide | Through Hole | Stainless Steel | Glass Filled PBT Polybutylene Terephthalate | 6 µin | |
 Taoglas Limited | 0 °C | 70 °C | 90 ° | Right | Down | Green - Yellow | 10/100 Base-T AutoMDIX | Unshielded | 0.524 in | 4 | Phosphor Bronze | Gold | 1 | 1 | RJ45 | Solder | Board Guide | Through Hole | Stainless Steel | Glass Filled PBT Polybutylene Terephthalate | 6 µin | |
 Taoglas Limited | -40 °C | 85 °C | 90 ° | Right | Down | Green - Yellow | 1G Base-T AutoMDIX | EMI Finger Shielded | 0.527 in | 8 | Phosphor Bronze | Gold | 4 | 1 | RJ45 | Solder | Board Guide | Through Hole | Stainless Steel | Glass Filled PBT Polybutylene Terephthalate | 6 µin |
