OP550 Series

Catalog

SENSOR PHOTO 935NM SIDE VIEW RAD

Part	Wavelength	Voltage - Collector Emitter Breakdown (Max) [Max]	Power - Max [Max]	Current - Collector (Ic) (Max) [Max]	Package / Case	Orientation [custom]	Current - Dark (Id) (Max) [Max]	Mounting Type	Operating Temperature [Min]	Operating Temperature [Max]
TT Electronics/BI OP550A	935 nm	30 V	100 mW	4.7 mA	Radial	Side View	100 nA	Through Hole	-40 C	100 °C
TT Electronics/BI OP550C	935 nm	30 V	100 mW	2.4 mA	Radial	Side View	100 nA	Through Hole	-40 C	100 °C
