TE EW60 Series
Manufacturer: TE Connectivity AMP Connectors
Beta
⌘K
EW60-1A3-BL24D04,00000
| Part | Coil Resistance | Coil Voltage | Switching Voltage [Max] | Load - Max Switching [Max] | Termination Style | Mounting Type | Contact Material | Approval Agency | Contact Rating (Current) | Operating Temperature [Max] | Operating Temperature [Min] | Operate Time | Coil Current | Coil Type | Must Operate Voltage | Relay Type | Contact Form |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TE Connectivity AMP Connectors | |||||||||||||||||
 TE Connectivity AMP Connectors | |||||||||||||||||
 TE Connectivity AMP Connectors | 48 Ohms | 12 VDC | 440 VAC | 26400 VA | PC Pin | Through Hole | Silver Tin Oxide (AgSnO) | UL | 60 A | 70 °C | -40 C | 100 ms | 250 mA | Dual Coil Latching | 9.6 VDC | General Purpose | SPST-NO (1 Form A) |
 TE Connectivity AMP Connectors | 12 VDC | 440 VAC | 26400 VA | PC Pin | Through Hole | Silver Tin Oxide (AgSnO) | UL | 60 A | 70 °C | -40 C | 100 ms | 125 mA | Latching Single Coil | 9.6 VDC | General Purpose | SPST-NO (1 Form A) |
