45379/15 Series
Manufacturer: ALPHA WIRE
Beta
⌘K
MULTI-PAIR 30COND 18AWG 1000'
| Part | Shield Coverage | Shield Material | Conductor Material | Shield Type | Jacket (Insulation) Thickness | Jacket (Insulation) Thickness [custom] | Features | Ratings | Conductor Insulation | Conductor Insulation | Jacket (Insulation) Material | Jacket Color | Wire Gauge | Number of Conductors | Length | Length | Cable Type | Jacket (Insulation) Diameter [diameter] | Jacket (Insulation) Diameter [diameter] | Voltage | Operating Temperature [Max] | Operating Temperature [Min] | Conductor Strand [custom] | Conductor Strand [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 ALPHA WIRE | 100 % | Aluminum | Copper Tinned | Foil | 1.651 mm | 0.065 in | Biological Compatibility Drain Wire Rip Cord | ISO 10993 | TPE | Thermoplastic Elastomer | Thermoplastic Elastomer (TPE) | Black | 18 AWG | 30 | 304.8 m | 1000 ft | Multi-Pair | 18.69 mm | 0.736 in | 300 VDC | 125 °C | -50 °C | 16 | 30 AWG |
 ALPHA WIRE | 100 % | Aluminum | Copper Tinned | Foil | 1.651 mm | 0.065 in | Biological Compatibility Drain Wire Rip Cord | ISO 10993 | TPE | Thermoplastic Elastomer | Thermoplastic Elastomer (TPE) | Slate | 18 AWG | 30 | 304.8 m | 1000 ft | Multi-Pair | 18.69 mm | 0.736 in | 300 VDC | 125 °C | -50 °C | 16 | 30 AWG |
