1.15108 Series
Manufacturer: RAFI USA
Beta
⌘K
PUSHBUTTON SWITCHES LUMOTAST 75 IP65 PSHBTN RECTANGLE
| Part | Switch Function | Termination Style | Mechanical Life | Electrical Life | Actuator Marking | Operating Temperature [Min] | Operating Temperature [Max] | Circuit | Voltage Rating - DC | Actuator Type | Current Rating (Amps) | Type | Panel Cutout Dimensions [diameter] | Ingress Protection | Voltage Rating - AC | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 RAFI USA | Off-On On-Off | Solder Lug | 50000 Cycles | 50000 Cycles | No Marking | -25 °C | 70 °C | 4PST-2NO/2NC | 230 V | Button Rectangular | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP65 - Dust Tight Water Resistant | 250 V | Panel Mount Front |
 RAFI USA | Off-Mom On-Mom | Solder Lug | No Marking | -25 °C | 70 °C | 4PST-2NO/2NC | 230 V | Button Round | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP40 | 250 V | Panel Mount Front | ||
 RAFI USA | Off-On On-Off | Solder Lug | No Marking | -25 °C | 70 °C | DPST-NO/NC | 230 V | Button Round | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP40 | 250 V | Panel Mount Front | ||
 RAFI USA | Off-On On-Off | Solder Lug | No Marking | -25 °C | 70 °C | 4PST-2NO/2NC | 230 V | Button Round | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP40 | 250 V | Panel Mount Front | ||
RAFI USA | Off-On On-Off | Solder Lug | No Marking | -25 °C | 70 °C | 4PST-2NO/2NC | 230 V | Button Round | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP40 | 250 V | Panel Mount Front | ||
 RAFI USA | Off-Mom On-Mom | Solder Lug | No Marking | -25 °C | 70 °C | DPST-NO/NC | 230 V | Button Round | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP65 - Dust Tight Water Resistant | 250 V | Panel Mount Front | ||
 RAFI USA | Off-Mom On-Mom | Solder Lug | No Marking | -25 °C | 70 °C | 4PST-2NO/2NC | 230 V | Button Square | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP40 | 250 V | Panel Mount Front | ||
RAFI USA | Off-On On-Off | Solder Lug | No Marking | -25 °C | 70 °C | DPST-NO/NC | 230 V | Button Round | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP40 | 250 V | Panel Mount Front | ||
 RAFI USA | Off-On On-Off | Solder Lug | No Marking | -25 °C | 70 °C | DPST-NO/NC | 230 V | Button Square | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP40 | 250 V | Panel Mount Front | ||
RAFI USA | Off-On On-Off | Solder Lug | No Marking | -25 °C | 70 °C | 4PST-2NO/2NC | 230 V | 4 A 200 mA | Illuminated Standard | 16.2 mm | IP65 - Dust Tight Water Resistant | 250 V | Panel Mount Front |
