UHE-15 Series
Manufacturer: Murata Electronics
Beta
⌘K
DC DC CONVERTER 15V 30W
| Part | Voltage - Input (Min) [Min] | Efficiency | Voltage - Input (Max) [Max] | Power (Watts) | Operating Temperature [Max] | Operating Temperature [Min] | Type | Mounting Type | Package / Case | Features | Current - Output (Max) [Max] | Voltage - Output 1 | Number of Outputs | Applications | Control Features | Voltage - Isolation | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [y] | Size / Dimension [y] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Murata Electronics | 36 V | 92 % | 75 V | 30 Watts | 85 °C | -40 C | Isolated Module | Through Hole | 9-DIP Module 6 Leads | OCP OTP Remote On/Off SCP UVLO | 2 A | 15 V | 1 | ITE (Commercial) | Active High Enable | 1.5 kV | 2 in | 0.4 " | 10.2 mm | 50.8 mm | 1.6 in | 40.6 mm |
