ECE-T2 Series

Manufacturer: Panasonic Electronic Components

Catalog

CAP ALUM 560UF 20% 450V SNAP TH

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Capacitance	Package / Case	Operating Temperature [Max]	Operating Temperature [Min]	Lifetime @ Temp.	Mounting Type	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Lead Spacing	Lead Spacing	Applications	Ripple Current @ High Frequency	ESR (Equivalent Series Resistance)	Tolerance	Polarization	Ripple Current @ Low Frequency	Voltage - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]
Panasonic Electronic Components ECE-T2WP561EA	1.378 "	35 mm	560 µF	Radial Can - Snap-In - 4 Lead	85 °C	-25 °C	3000 Hrs	Through Hole	2.48 in	63 mm	0.886 in	22.5 mm	General Purpose	4.06 A	355 mOhm	20 %	Polar	2.9 A	450 V
Panasonic Electronic Components ECE-T2AA123FA	1.575 in	40 mm	12000 µF	Radial Can - Snap-In - 4 Lead	105 ░C	-40 C	3000 Hrs	Through Hole			0.886 in	22.5 mm	General Purpose		21 mOhms	20 %	Polar	6.44 A	100 V	3.15 "	80 mm
Panasonic Electronic Components ECE-T2DP392FA	1.575 in	40 mm	3900 µF	Radial Can - Snap-In - 4 Lead	85 °C	-40 C	3000 Hrs	Through Hole			0.886 in	22.5 mm	General Purpose		64 mOhm	20 %	Polar		200 VDC	3.15 "	80 mm
Panasonic Electronic Components ECE-T2DA272EA	1.378 "	35 mm	2700 µF	Radial Can - Snap-In - 4 Lead	105 ░C	-40 C	3000 Hrs	Through Hole	2.48 in	63 mm	0.886 in	22.5 mm	General Purpose	5.11 A	80 mOhm	20 %	Polar	3.65 A	200 VDC
Panasonic Electronic Components ECE-T2WP122FA	1.575 in	40 mm	1.2 mF	Radial Can - Snap-In - 4 Lead	85 °C	-25 °C	3000 Hrs	Through Hole			0.886 in	22.5 mm	General Purpose	6.776 A	166 mOhm	20 %	Polar	4.84 A	450 V	3.15 "	80 mm
Panasonic Electronic Components ECE-T2VP102EA	1.378 "	35 mm	1000 µF	Radial Can - Snap-In - 4 Lead	85 °C	-25 °C	3000 Hrs	Through Hole	2.48 in	63 mm	0.886 in	22.5 mm	General Purpose	5.32 A	249 mOhm	20 %	Polar	3.8 A	350 V
Panasonic Electronic Components ECE-T2GA821FA	1.575 in	40 mm	820 µF	Radial Can - Snap-In - 4 Lead	105 ░C	-25 °C	3000 Hrs	Through Hole	1.969 in	50 mm	0.886 in	22.5 mm	General Purpose	3.612 A	202 mOhm	20 %	Polar	3 A	400 V
Panasonic Electronic Components ECE-T2EA122EA	1.378 "	35 mm	1.2 mF	Radial Can - Snap-In - 4 Lead	105 ░C	-40 C	3000 Hrs	Through Hole	1.969 in	50 mm	0.886 in	22.5 mm	General Purpose	3.22 A	180 mOhms	20 %	Polar	2.3 A	250 V
Panasonic Electronic Components ECE-T2EP222EX	1.378 "	35 mm	2200 µF	Radial Can - Snap-In - 4 Lead	85 °C	-40 C	3000 Hrs	Through Hole	2.48 in	63 mm	0.886 in	22.5 mm	General Purpose	6.58 A	90 mOhm	20 %	Polar	4.7 A	250 V
Panasonic Electronic Components ECE-T2WP821FA	1.575 in	40 mm	820 µF	Radial Can - Snap-In - 4 Lead	85 °C	-25 °C	3000 Hrs	Through Hole	2.48 in	63 mm	0.886 in	22.5 mm	General Purpose	5.18 A	243 mOhm	20 %	Polar	3.7 A	450 V
