892-010 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SINGLE FML 10POS 0.100
| Part | Material - Insulation | Termination Rows | Gender | Mounting Type | Contact Material | Number of Positions | Pitch | Pitch | Color | Termination | Contact Finish Thickness | Contact Finish Thickness | Flange Feature [diameter] | Flange Feature | Flange Feature [diameter] | Number of Rows | Card Type | Operating Temperature [Max] | Operating Temperature [Min] | Contact Finish | Contact Type | Number of Positions/Bay/Row | Read Out | Card Thickness [Max] | Card Thickness [Min] | Termination Rows [custom] | Number of Rows [custom] | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder Eyelet(s) | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 1 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Cantilever | 10 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder | 0.25 Ám | 10 Áin | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Non Specified - Dual Edge | 125 °C | -40 C | Gold | Cantilever | 5 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder | 0.25 Ám | 10 Áin | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Non Specified - Dual Edge | 125 °C | -40 C | Gold | Cantilever | 5 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Wire Wrap | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 1 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Cantilever | 10 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Right Angle Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder | 0.25 Ám | 10 Áin | 4-40 Flush Mount Threaded Insert Top Opening | 1 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Cantilever | 10 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder | 0.25 Ám | 10 Áin | 0.116 " | Floating Bobbin Flush Mount | 2.95 mm | 1 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Cantilever | 10 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Board Edge Straddle Mount | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder | 0.25 Ám | 10 Áin | 0.128 " | Flush Mount Side Opening Unthreaded | 3.25 mm | Non Specified - Dual Edge | 125 °C | -40 C | Gold | Cantilever | 5 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | Card Extender | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Board Edge Straddle Mount | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder | 0.25 Ám | 10 Áin | 0.156 " | Flush Mount Top Opening Unthreaded | 3.96 mm | Non Specified - Dual Edge | 125 °C | -40 C | Gold | Cantilever | 5 | Dual | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 2 | 2 | Card Extender | ||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder Eyelet(s) | 0.25 Ám | 10 Áin | 0.128 " | Flush Mount Top Opening Unthreaded | 3.25 mm | 1 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Cantilever | 10 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | 1 | Female | Through Hole | Copper Alloy | 10 | 0.1 " | 2.54 mm | Black | Solder Eyelet(s) | 0.25 Ám | 10 Áin | Flush Mount M3 Threaded Insert Top Opening | 1 | Non Specified - Single Edge | 125 °C | -40 C | Gold | Cantilever | 10 | Single | 0.07 in 1.78 mm | 0.054 in 1.37 mm |
