307-037 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 37POS 0.156
| Part | Termination Rows | Material - Insulation | Card Thickness [Max] | Card Thickness [Min] | Contact Finish Thickness | Contact Finish Thickness | Number of Rows | Termination | Flange Feature | Pitch | Pitch | Contact Type | Number of Positions | Gender | Card Type | Operating Temperature [Min] | Operating Temperature [Max] | Features | Mounting Type | Contact Material | Read Out | Color | Contact Finish | Number of Positions/Bay/Row | Number of Rows [custom] | Flange Feature [diameter] | Flange Feature [diameter] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | 1 | Solder Eyelet(s) | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Semi Bellows | 37 | Female | Non Specified - Single Edge | -40 C | 105 ░C | Card Guides | Through Hole | Copper Alloy | Single | Green | Gold | 37 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Wire Wrap | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Semi Bellows | 74 | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Right Angle Through Hole | Copper Alloy | Dual | Green | Gold | 37 | 2 | 3.25 mm | 0.128 " | ||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | 3.96 mm | 0.156 in | Semi Bellows | 37 | Female | Non Specified - Single Edge | -40 C | 105 ░C | Right Angle Through Hole | Copper Alloy | Single | Green | Tin | 37 | |||||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Semi Bellows | 74 | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Right Angle Through Hole | Copper Alloy | Dual | Green | Tin | 37 | 2 | 3.96 mm | 0.156 " | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Semi Bellows | 74 | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Card Guides | Right Angle Through Hole | Copper Alloy | Dual | Green | Tin | 37 | 2 | |||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder Eyelet(s) | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Semi Bellows | 74 | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Card Guides | Through Hole | Copper Alloy | Dual | Green | Gold | 37 | 2 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Wire Wrap | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Semi Bellows | 74 | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Card Guides | Right Angle Through Hole | Copper Alloy | Dual | Green | Gold | 37 | 2 | |||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 0.25 Ám | 10 Áin | Solder | Flush Mount M3 Threaded Insert Top Opening | 3.96 mm | 0.156 in | Semi Bellows | 74 | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Through Hole | Copper Alloy | Dual | Green | Gold | 37 | 2 | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Solder Eyelet(s) | Flush Mount Top Opening Unthreaded | 3.96 mm | 0.156 in | Semi Bellows | 74 | Female | Non Specified - Dual Edge | -40 C | 105 ░C | Surface Mount | Copper Alloy | Dual | Green | Tin | 37 | 2 | 3.96 mm | 0.156 " | ||||
 EDAC Inc. | 1 | Polyester Thermoplastic | 0.07 in 1.78 mm | 0.054 in 1.37 mm | 1 | Solder | 4-40 Flush Mount Threaded Insert Top Opening | 3.96 mm | 0.156 in | Semi Bellows | 37 | Female | Non Specified - Single Edge | -40 C | 105 ░C | Right Angle Through Hole | Copper Alloy | Single | Green | Tin | 37 |
