PAA5 Series
Manufacturer: TT Electronics/BI
Beta
⌘K
ENCAPSULATED POWER SUPPLY 12V 5.04 WATT
| Part | Applications | Power (Watts) | Voltage - Input [Min] | Voltage - Input [Max] | Features | Current - Output (Max) [Max] | Number of Outputs | Size / Dimension [y] | Size / Dimension [z] | Size / Dimension [x] | Size / Dimension [z] | Size / Dimension [y] | Size / Dimension [x] | Type | Mounting Type | Standard Number | Voltage - Output 1 | Approval Agency | Package / Case | Efficiency | Load Regulation | Line Regulation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 TT Electronics/BI | Household Appliances ITE (Commercial) | 5.04 W | 90 VAC 127 VDC | 305 VAC 430 VDC | Universal Input | 420 mA | 1 | 1.08 in | 0.69 in | 1.46 in | 17.5 mm | 27.5 mm | 37 mm | Enclosed | Through Hole | 60335-1 62368-1 | 12 V | CB CE cURus | 5-DIP Module | 81 % | ||
 TT Electronics/BI | Household Appliances ITE (Commercial) | 5 W | 90 VAC 127 VDC | 305 VAC 430 VDC | Universal Input | 1 A | 1 | 1.08 in | 0.69 in | 1.46 in | 17.5 mm | 27.5 mm | 37 mm | Enclosed | Through Hole | 5 V | CB CE cURus | 5-DIP Module | 77 % | 0.5 % | 0.2 % |
