896-024 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE DUAL FMALE 24POS 0.125
| Part | Termination Rows [custom] | Material - Insulation | Gender | Contact Material | Contact Finish | Mounting Type | Number of Positions | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Type | Termination | Operating Temperature [Max] | Operating Temperature [Min] | Card Thickness [Max] | Card Thickness [Min] | Color | Contact Finish Thickness | Contact Finish Thickness | Pitch | Pitch | Card Type | Number of Rows [custom] | Number of Positions/Bay/Row | Read Out | Termination Rows | Number of Rows | Features |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Through Hole | 24 | Flush Mount Top Opening Unthreaded | 3.25 mm | 0.128 " | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 2 | 12 | Dual | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Through Hole | 24 | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | Solder Eyelet(s) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | Single | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Right Angle Through Hole | 24 | 3.25 mm | 0.128 " | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 2 | 12 | Dual | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Through Hole | 24 | Floating Bobbin Flush Mount | 2.95 mm | 0.116 " | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 2 | 12 | Dual | |||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Through Hole | 24 | 3.25 mm | 0.128 " | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | Single | 1 | 1 | ||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Board Edge Straddle Mount | 24 | 3.25 mm | 0.128 " | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 2 | 12 | Dual | Card Extender | |||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Board Edge Straddle Mount | 24 | M3 Threaded Insert Top Mount Opening | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 2 | 12 | Dual | Card Extender | ||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Through Hole | 24 | 4-40 Flush Mount Threaded Insert Top Opening | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | Single | 1 | 1 | |||||
 EDAC Inc. | 2 | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Through Hole | 24 | Flush Mount M3 Threaded Insert Top Opening | Cantilever | Solder Eyelet(s) | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Dual Edge | 2 | 12 | Dual | |||||
 EDAC Inc. | Polyphenylene Sulfide (PPS) | Female | Copper Alloy | Gold | Through Hole | 24 | Cantilever | Solder | 125 °C | -40 C | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Black | 0.25 Ám | 10 Áin | 3.18 mm | 0.125 in | Non Specified - Single Edge | 24 | Single | 1 | 1 |
