292206 Series

Manufacturer: TE Connectivity Raychem Cable Protection

Catalog

CONN SHROUDED HEADER HDR 7 POS 1.5MM SOLDER RA THRU-HOLE BOX/TRAY

Part	Contact Length - Post	Contact Length - Post	Contact Type	Current Rating (Amps)	Number of Positions	Fastening Type	Contact Length - Mating [custom]	Contact Length - Mating [custom]	Contact Shape	Applications	Termination	Number of Positions Loaded	Contact Material	Connector Type	Contact Finish - Post	Insulation Material	Number of Rows	Material Flammability Rating	Voltage Rating	Style	Operating Temperature [Min]	Operating Temperature [Max]	Insulation Height	Insulation Height	Shrouding	Insulation Color	Mounting Type
TE Connectivity Raychem Cable Protection 292206-7	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	7	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Gray	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 5-292206-9	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	9	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Blue	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 292206-3	0.118 in	3 mm	Male Pin	Varies by Wire Gauge		Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Gray	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 2-292206-0	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	20	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Gray	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 6-292206-5	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	15	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Blue	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 6-292206-1	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	11	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Blue	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 1-292206-7	0.118 in	3 mm	Male Pin	Varies by Wire Gauge		Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Gray	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 1-292206-2	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	12	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Gray	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 1-292206-0	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	10	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Gray	Through Hole Right Angle
TE Connectivity Raychem Cable Protection 292206-4	0.118 in	3 mm	Male Pin	Varies by Wire Gauge	4	Detent Lock	2.4 mm	0.094 in	Square	General Purpose	Kinked Pin Solder	All	Brass	Header	Tin	Glass Filled Nylon Polyamide (PA)	1	UL94 V-0	50 VAC	Board to Cable/Wire	-30 ░C	105 ░C	4.9 mm	0.193 in	Shrouded - 4 Wall	Gray	Through Hole Right Angle
