G51ME7-P Series
Manufacturer: ODU
Beta
⌘K
ODU MEDI-SNAP RECEPT, STY 5, SZ
| Part | Mounting Type | Color | Mounting Feature | Fastening Type | Shell Size - Insert | Voltage Rating | Contact Finish - Mating | Number of Positions | Material Flammability Rating | Applications | Connector Type | Shielding | Current Rating (Amps) | Ingress Protection | Insert Material | Shell Material | Primary Material | Contact Material | Operating Temperature [Max] | Operating Temperature [Min] | Orientation | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Panel Mount | Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 35 V | Gold | 5 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 7.5 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | ||
Panel Mount Through Hole | Blue Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 35 V | Gold | 5 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 7.5 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | Solder | |
Panel Mount Through Hole | Blue Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 48 VDC | Gold | 4 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 7.5 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | Solder | |
Panel Mount Through Hole | Blue Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 36 VDC | Gold | 6 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 6 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | Solder | |
Panel Mount | Blue Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 35 V | Gold | 5 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 7.5 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | ||
Panel Mount | Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 25 V | Gold | 14 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 4 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | ||
Panel Mount Through Hole | Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 25 V | Gold | 10 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 4 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | Solder | |
Panel Mount Through Hole | Gray | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 35 V | Gold | 5 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 7.5 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | Solder | |
Panel Mount | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 48 VDC | Gold | 4 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 7.5 A | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E | |||
Panel Mount | Gray Red | Bulkhead - Front or Rear Side Nut | Detent Lock Push-Pull | 1 | 48 VDC | Gold | 2 | UL94 V-0 | Industrial Medical Testing Equipment & Measurement | Receptacle Female Sockets | Unshielded | 12 Amps | IP50 - Dust Protected | Polyetheretherketone (PEEK) | Polysulfone (PSU) | Plastic | Brass | 120 °C | -50 °C | E |
