MAX77950 Series

The MAX77950 is an advanced wireless power receiver IC that meets the specification requirements for WPC low-power (v1.2) and PMA SR1 (v2.0) communication protocols. This device operates using near-field magnetic induction when coupled with a WPC or PMA transmitter and provides output power up to 12 watts.The IC has precision output current and voltage-sensing scheme over the entire load range. It enables accurate received power packets, as defined in the WPC specifications for best foreign object detection (FOD). The IC supports FSK demodulation to receive PMA advertisement ID as well as WPC FSK packets.The IC features the patent-pending PeerPower™ function. In PeerPower mode, the IC operates as a transmitter, enabling power transfer to another peer device through in-band ASK communications.The MAX77950 communicates with an application processor through an I2C serial interface. The status of power transfer and alerts are read through this interface.Design Solution: Let Your Smartphone Power Your Smartwatch Wirelessly ›ApplicationsBattery-Power BanksDigital CamerasHandheld DevicesHeadsetsPoint-of-Sale DevicesPortable Media PlayersPortable Medical ApplicationsSmart WatchesSmartphonesTabletsWearable DevicesWi-Fi Hotspots
