1571995 Series
Manufacturer: TE Connectivity Raychem Cable Protection
Beta
⌘K
CONN SOCKET SIP 12POS GOLD
| Part | Contact Finish Thickness - Post | Contact Finish Thickness - Post | Mounting Type | Contact Finish - Post | Features | Contact Material - Mating | Type | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) | Material Flammability Rating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Housing Material | Pitch - Mating | Pitch - Mating | Termination | Contact Material - Post | Pitch - Post | Pitch - Post | Termination Post Length | Termination Post Length | Contact Finish - Mating | Number of Positions or Pins (Grid) [custom] | Number of Positions or Pins (Grid) [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
TE Connectivity Raychem Cable Protection | 20 µin | 0.51 µm | Through Hole | Tin | Closed Frame | Beryllium Copper | SIP | 1 x 12 | 12 | UL94 V-0 | 0.51 µm | 20 µin | Polyester Thermoplastic | 0.1 in | 2.54 mm | Solder | Copper | 2.54 mm | 0.1 in | 3.18 mm | 0.125 in | Gold | ||
 TE Connectivity Raychem Cable Protection | 20 µin | 0.51 µm | Through Hole | Tin | Closed Frame | Beryllium Copper | SIP | UL94 V-0 | Polyester Thermoplastic | 0.1 in | 2.54 mm | Solder | Copper | 2.54 mm | 0.1 in | 3.18 mm | 0.125 in | 2 x 5 | 10 |
