18980-7P Series
Manufacturer: SWITCHCRAFT/CONXALL
Beta
⌘K
CIRCULAR CONNECTOR, MICRO-CON-X SERIES, CABLE MOUNT PLUG, 7 CONTACTS, CRIMP PIN, BAYONET
| Part | Features | Contact Material | Primary Material | Current Rating (Amps) | Termination | Fastening Type | Cable Opening [Min] | Cable Opening [Max] | Cable Opening [Max] | Cable Opening [Min] | Mounting Type | Ingress Protection | Number of Positions | Backshell Material, Plating | Color | Shielding | Contact Finish - Mating | Operating Temperature [Max] | Operating Temperature [Min] | Material Flammability Rating | Voltage Rating | Applications | Connector Type | Orientation |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 SWITCHCRAFT/CONXALL | Backshell | Copper Alloy | Plastic | 3.5 A | Crimp | Bayonet Lock | 5.59 mm | 5.84 mm | 0.23 in | 0.22 in | Free Hanging (In-Line) | IP67 - Dust Tight Waterproof | 7 | Thermoplastic | Black | Unshielded | Gold | 85 °C | -40 C | UL94 HB | 600 VAC | Data Industrial Instrumentation Medical | Receptacle Male Pins | B |
