1.5SMC Series

Manufacturer: YAGEO

Catalog

ESD PROTECTION DIODES / TVS DIODES 1.5SMC - CA 23.1V

Part	Mounting Type	Bidirectional Channels [custom]	Type	Voltage - Reverse Standoff (Typ)	Power - Peak Pulse	Power - Peak Pulse	Voltage - Clamping (Max) @ Ipp [Max]	Package / Case	Voltage - Breakdown (Min) [Min]	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Supplier Device Package	Current - Peak Pulse (10/1000µs)	Unidirectional Channels [custom]	Grade	Qualification
YAGEO 1.5SMC27CA/TR7	Surface Mount	1	Zener	23.1 V	1.5 kW	1500 W	37.5 V	DO-214AB SMC	25.7 V	150 °C	-55 °C	General Purpose	DO-214AB (SMC)
YAGEO 1.5SMC68A/TR7	Surface Mount		Zener	58.1 V	1.5 kW	1500 W	92 V	DO-214AB SMC	64.6 V	150 °C	-55 °C	General Purpose	DO-214AB (SMC)	16.5 A	1
YAGEO 1.5SMC350CA-AT/7	Surface Mount	1	Zener	300 V	1.5 kW	1500 W	482 V	DO-214AB SMC	332 V	150 °C	-55 °C		DO-214AB (SMC)	3.2 A		Automotive	AEC-Q101
YAGEO 1.5SMC170A/TR13	Surface Mount		Zener	145 V	1.5 kW	1500 W	234 V	DO-214AB SMC	162 V	150 °C	-55 °C	General Purpose	DO-214AB (SMC)	6.5 A	1
YAGEO 1.5SMC15A/TR13	Surface Mount		Zener	12.8 V	1.5 kW	1500 W	21.2 V	DO-214AB SMC	14.3 V	150 °C	-55 °C	General Purpose	DO-214AB (SMC)	71.7 A	1
YAGEO 1.5SMC36A/TR7	Surface Mount		Zener	30.8 V	1.5 kW	1500 W	49.9 V	DO-214AB SMC	34.2 V	150 °C	-55 °C	General Purpose	DO-214AB (SMC)	30.5 A	1
YAGEO 1.5SMC13A-AT/7	Surface Mount		Zener	11.1 V	1.5 kW	1500 W	18.2 V	DO-214AB SMC	12.4 V	150 °C	-55 °C		DO-214AB (SMC)	83.5 A	1	Automotive	AEC-Q101
YAGEO 1.5SMC480A-AT/13	Surface Mount		Zener		1.5 kW	1500 W	658 V	DO-214AB SMC	456 V	150 °C	-55 °C		DO-214AB (SMC)	2.3 A	1	Automotive	AEC-Q101
YAGEO 1.5SMC24A-AT/7	Surface Mount		Zener	20.5 V	1.5 kW	1500 W	33.2 V	DO-214AB SMC	22.8 V	150 °C	-55 °C		DO-214AB (SMC)	45.8 A	1	Automotive	AEC-Q101
YAGEO 1.5SMC24CA/TR7	Surface Mount	1	Zener	20.5 V	1.5 kW	1500 W	33.2 V	DO-214AB SMC	22.8 V	150 °C	-55 °C	General Purpose	DO-214AB (SMC)	45.8 A
