KX Series
Manufacturer: Panasonic Electronic Components
Beta
⌘K
ALUMINUM ORGANIC POLYMER CAPACITORS 6.3BDC 120UF 5100MA 15MOHM
| Part | Capacitance | Size / Dimension [y] | Size / Dimension [x] | Size / Dimension [x] | Size / Dimension [y] | Tolerance | Voltage - Rated | Package / Case | Surface Mount Land Size [x] | Surface Mount Land Size [y] | Surface Mount Land Size [y] | Surface Mount Land Size [x] | Lifetime @ Temp. | Type | Mounting Type | ESR (Equivalent Series Resistance) | Height - Seated (Max) [Max] | Height - Seated (Max) [Max] | Operating Temperature [Min] | Operating Temperature [Max] | Ripple Current @ High Frequency | Applications |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Panasonic Electronic Components | 120 µF | 0.169 " | 7.3 mm | 0.287 " | 4.3 mm | 20 % | 6.3 VDC | 2917 (7343 Metric) | 7.3 mm | 4.3 mm | 0.169 " | 0.287 " | 5500 Hrs | Polymer | Surface Mount | 15 mOhm | 0.079 in | 2 mm | -55 C | 125 °C | 5.1 A | General Purpose |
