561R Series

Catalog

CERAMIC DISC CAPACITORS 561R1DF0T22JK E3

Part	Features	Mounting Type	Size / Dimension Diameter	Lead Spacing	Applications	Operating Temperature (Min)	Operating Temperature (Max)	Temperature Coefficient	Lead Style	Capacitance	Package / Case	Tolerance	Voltage - Rated	Height - Seated (Max)
Vishay Dale 561R1DF0T22JK	Low Dissipation Factor	Through Hole	0.252 in	0.252 in	General Purpose	-55 °C	105 °C	N2500	Straight	220 pF	Disc Radial	10 %	1000 V
Vishay Dale 561R10TCCT10	Low Dissipation Factor	Through Hole	0.559 in	0.374 in	General Purpose	-55 °C	105 °C	C0G NP0	Straight	100 pF	Disc Radial	5 %	1000 V	0.684 in
Vishay Dale 561R10TCCQ10BA	Low Dissipation Factor	Through Hole	0.252 in	0.252 in	General Purpose	-55 °C	105 °C	C0G NP0	Straight	10 pF	Disc Radial	5 %	1000 V	0.377 in
Vishay Dale 561R1DF0Q10	Low Dissipation Factor	Through Hole	0.252 in	0.252 in	General Purpose	-55 °C	105 °C	C0G NP0	Straight	10 pF	Disc Radial	5 %	1000 V
Vishay Dale 561R10TCCV10BA	Low Dissipation Factor	Through Hole	0.252 in	0.252 in	General Purpose	-55 °C	105 °C	C0K	Straight	1 pF	Disc Radial	0.5 pF	1000 V	0.377 in
Vishay Dale 561R1DF0T15	Low Dissipation Factor	Through Hole	0.252 in	0.252 in	General Purpose	-55 °C	105 °C	N2000	Straight	150 pF	Disc Radial	10 %	1000 V
Vishay Dale 561R1DF0T18	Low Dissipation Factor	Through Hole	0.252 in	0.252 in	General Purpose	-55 °C	105 °C	N2000	Straight	180 pF	Disc Radial	10 %	1000 V
Vishay Dale 561R10TCUT56	Low Dissipation Factor	Through Hole	0.65 in	0.374 in	General Purpose	-55 °C	105 °C	U2J	Straight	560 pF	Disc Radial	5 %	1000 V	0.684 in
