887-033 Series
Manufacturer: EDAC Inc.
Beta
⌘K
CONN EDGE SGL FMALE 33POS 0.156
| Part | Termination Rows | Material - Insulation | Pitch | Pitch | Flange Feature | Flange Feature [diameter] | Flange Feature [diameter] | Contact Finish | Gender | Termination | Read Out | Operating Temperature [Max] | Operating Temperature [Min] | Contact Material | Number of Rows | Number of Positions/Bay/Row | Contact Type | Card Type | Contact Finish Thickness | Contact Finish Thickness | Card Thickness [Max] | Card Thickness [Min] | Mounting Type | Color | Number of Positions [custom] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Floating Bobbin Top Mount Opening | 0.116 " | 2.95 mm | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Black | 33 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | 4-40 Threaded Insert Top Mount Opening | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Black | 33 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | 4-40 Threaded Insert Top Mount Opening | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Black | 33 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Floating Bobbin Flush Mount | 0.116 " | 2.95 mm | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Black | 33 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | 0.128 " | 3.25 mm | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Black | 33 | |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Black | 33 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Flush Mount Top Opening Unthreaded | 0.156 " | 3.96 mm | Gold | Female | Wire Wrap | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Black | 33 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | M3 Threaded Insert Top Mount Opening | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Right Angle Through Hole | Black | 33 | ||
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | Side Mount Opening Unthreaded | 0.128 " | 3.25 mm | Gold | Female | Wire Wrap | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Black | 33 |
 EDAC Inc. | 1 | Polyphenylene Sulfide (PPS) | 3.96 mm | 0.156 in | 4-40 Flush Mount Threaded Insert Top Opening | Gold | Female | Solder | Single | 125 °C | -40 C | Copper Alloy | 1 | 33 | Cantilever | Non Specified - Single Edge | 0.25 Ám | 10 Áin | 0.07 in 1.78 mm | 0.054 in 1.37 mm | Through Hole | Black | 33 |
